Travis Steel, located in Canberra, Australia, stands out as a top manufacturer and supplier of ARCELOR 500 Sheets and Plates, specifically designed for high-strength and demanding industrial uses. Known for their precision, durability, and compliance with international standards, Travis Steel guarantees consistent quality and exceptional structural performance in every product they offer. Thanks to advanced manufacturing techniques and strict quality control measures, ARCELOR 500 Sheets and Plates are crafted with precise dimensions, uniform mechanical properties, and remarkable toughness. Built to endure extreme conditions, these high-strength sheets and plates are perfect for construction, heavy engineering, mining equipment, and any other applications that require reliable, wear-resistant, and durable steel solutions.
The composition of ARCELOR 500 Sheets and Plates primarily includes carbon, manganese, phosphorus, sulfur, and trace elements, all optimized to achieve a high tensile strength of around 500 MPa while ensuring excellent toughness and impact resistance. Their mechanical properties boast superior hardness, yield strength, and elongation, enabling the steel to handle heavy loads and extreme stress. Heat treatment and controlled rolling processes further enhance their dimensional stability and wear resistance. ARCELOR 500 Sheets and Plates are engineered to deliver long-term reliability, consistent performance, and durability in tough industrial settings where both strength and toughness are essential.
Item: ARCELOR 500
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| Plate Thickness MM | %C Max | %Mn Max | %P Max | %S Max | %SI Max | %Cr Max | %Ni Max | %Mo Max | B Max | CE Max | PCM Max |
| 6.0 – 20.0 | 0.60 | 0.41 | |||||||||
| 21.0 – 40.0 | 0.30 | 1.60 | 0.025 | 0.010 | 0.70 | 1.50 | 1.50 | 0.70 | 0.040 | 0.65 | 0.43 |
| 41.0 – 50.0 | 0.74 | 0.48 |
| Â | Hardness HBW | Typical yield strength MPa, |
| mm | (min – max 1) | not guaranteed |
| 4 – 32 | 470 – 530 | 1250 |
| (32) – 103 | 450 – 540 | 1250 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
