Travis Steel, located in Canberra, Australia, stands out as a top-notch manufacturer and supplier of ASTM A572 Gr 50 Sheets and Plates. These products are celebrated for their impressive strength, durability, and versatility in various structural applications. With a strong commitment to quality and precision, Travis Steel ensures that their sheets and plates adhere to strict international standards, guaranteeing reliable mechanical performance and precise dimensions. Thanks to cutting-edge production methods and thorough quality checks, ASTM A572 Gr 50 Sheets and Plates offer remarkable toughness and dependability. They’re a go-to choice in construction, heavy engineering, and infrastructure projects where strength and long-lasting performance are essential, especially in tough conditions.
The composition of ASTM A572 Gr 50 Sheets and Plates includes carbon, manganese, phosphorus, sulfur, and trace amounts of silicon, all of which contribute to their outstanding strength and toughness. These materials boast a minimum yield strength of 50 ksi (345 MPa), along with high tensile strength and good elongation, ensuring dependable structural performance even under pressure. The steel maintains consistent hardness, dimensional stability, and excellent weldability, making it perfect for fabrication and construction. Advanced rolling and heat treatment processes further boost durability and wear resistance, allowing ASTM A572 Gr 50 Sheets and Plates to perform well in challenging environments.
| Specifications | : | ASME SA572 / ASTM A572 |
|---|---|---|
| Width | : | 1500-4020mm |
| Length | : | 3000-27000mm |
| Thickness | : | 8-300mm |
| Hardness | : | As per ASME A & NACE MR 175 |
| Impact tested | : | Impact tested -52° C |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Grade | C | Mn | P | V | Ni | Co | S | Si |
| A572 Grade 50 | 0.23 | 1.35 | 0.04 | 0.06 | 0.015 | 0.05 | 0.05 | 0.4 |
| Grade | Thickness | Yield | Tensile | Elongation |
| A572 Grade 50 | 8mm-200mm | MPa -345 min | MPa – 450 | 18-21% |
| Grade | India IS | England BS | Sweden MNC | Belgium NBN | Europe EN | Russia GOST |
| A572 Grade 50 Plate | FE410WC | 43EE | SS14,14，01 | AE 295 DD | S275 J2G3 Fe430 D2 S275NL |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| GRADE | GAUGE (INCHES) | WIDTH (INCHES) | LENGTH (INCHES) |
| A572 | 0.1875 | 96 | 240/480 |
| A572 | 0.2500 | 60/96/120 | 240/480 |
| A572 | 0.3125 | 60/96/120 | 240/480 |
| A572 | 0.3750 | 60/96/120 | 240/480 |
| A572 | 0.5000 | 60/96/120 | 240/480 |
| A572 | 0.6250 | 60/96/120 | 240/480 |
| A572 | 0.7500 | 60/96/120 | 240/480 |
| A572 | 0.8750 | 60/96/120 | 240/480 |
| A572 | 1.0000 | 60/96/120 | 240/480 |
| A572 | 1.1250 | 60/96/120 | 240/480 |
| A572 | 1.2500 | 60/96/120 | 240/480 |
| A572 | 1.5000 | 60/96/120 | 240/480 |
| A572 | 1.7500 | 60/96/120 | 240/480 |
| A572 | 2.0000 | 60/96/120 | 240/480 |
| A572 | 2.2500 | 96 | 240/480 |
| A572 | 2.5000 | 96 | 240/480 |
| A572 | 2.7500 | 96 | 240/480 |
| A572 | 3.0000 | 96 | 240/480 |
| A572 | 3.2500 | 96 | 240 |
| A572 | 3.5000 | 96 | 240 |
| A572 | 3.7500 | 96 | 240 |
| A572 | 4.0000 | 96 | 240 |
| A572 | 5.0000 | 96 | 240 |
| A572 | 6.0000 | 96 | 240 |
These sheets and plates are extensively utilized in building construction, bridges, heavy machinery, structural components, and various infrastructure projects. They’re particularly suited for load-bearing structures, steel frameworks, and applications that require a high strength-to-weight ratio. The blend of toughness, weldability, and resistance to environmental stress makes them ideal for both onshore and offshore projects. ASTM A572 Gr 50 Sheets and Plates deliver reliable, long-lasting solutions for industries that require high-performance structural steel, ensuring safety, durability, and efficiency in demanding engineering and construction scenarios.
