Carbon Steel DIN 17175 Pipe Manufacturer and Supplier in Canberra, Australia

Carbon Steel DIN 17175 Pipe

Worldwide Shipping

Largest
Inventory

Modern
Equipments

Expert
Engineers

Efficient Factories

Well
Maintained

Travis Steel, a top-notch manufacturer and supplier located in Canberra, Australia, is all about delivering high-quality Carbon Steel DIN 17175 Pipes. These pipes are designed to offer outstanding strength, durability, and dependable performance, especially in tough industrial settings. Crafted with cutting-edge technology and premium carbon steel, they boast impressive mechanical properties, toughness, and resistance to wear and corrosion. Travis Steel makes it a point to ensure that every Carbon Steel DIN 17175 Pipe adheres to strict international quality standards, making them perfect for critical tasks in construction, petrochemical, energy, and mechanical engineering sectors. Renowned for their long-lasting reliability, these pipes consistently provide safety and efficiency, even in high-pressure and challenging environments.

17175 Carbon Steel Thin Wall Pipe Supplier in Canberra, DIN 17175 CS Pipe Exporter in Adelaide, 17175 Carbon Steel Pipe Sizes in mm, DIN 17175 CS Pipe Manufacturer in Melbourne, Carbon Steel DIN 17175 Pipes Price List in Australia, Large Diameter DIN 17175 Carbon Steel Pipe Distributor in Sydney, Carbon Steel DIN 17175 Pipes in Brisbane, Carbon Steel 17175 Pipes Supplier in Melbourne, DIN 17175 CS Pipes Distributor in Australia

Carbon Steel DIN 17175 Seamless Pipes

Carbon Steel DIN 17175 Welded Pipes

Carbon Steel DIN 17175 EFW Pipes

What is Carbon Steel DIN 17175 Pipe?

When it comes to composition, Carbon Steel DIN 17175 Pipes mainly consist of iron and carbon, with carefully controlled amounts of manganese and silicon to boost their mechanical strength and toughness. They showcase high tensile and yield strength, excellent hardness, and good ductility, making them a great fit for high-pressure, high-temperature, and structural applications. These pipes maintain their shape, mechanical integrity, and resistance to wear and deformation, even when faced with varying temperatures and operational stresses. This combination of properties guarantees reliable long-term performance, durability, and structural stability, making Carbon Steel DIN 17175 Pipes a go-to choice for demanding industrial and engineering tasks.

ASME SA213 DIN 17175 Pipe Exporter in Australia, Carbon Steel DIN 17175 Pipes Price List in Canberra, DIN 17175 CS Pipes Supplier in Adelaide, Carbon Steel DIN 17175 Pipes Exporter in Melbourne, DIN 17175 Carbon Steel Pipes Exporter in Sydney, ASTM A213 Carbon Steel DIN 17175 Pipes Size Chart, Carbon Steel DIN 17175 Pipes Price in Brisbane, DIN 17175 Carbon Steel Pipe Weight Chart, Schedule 40 DIN 17175 Carbon Steel Pipe Thickness, DIN 17175 Pipes Supplier in Australia, Carbon Steel DIN 17175 Pipes Stockist in Adelaide

Carbon Steel DIN 17175 Pipe Specifications

Dimensions : ASTM, ASME and API
Standard : BS 3059
Outside Diameter : 5-90 mm
Wall Thickness : 0.5-15 mm
Length :in any length from 4 m to 12 m as per customer choice
Type :Seamless, Welded, ERW
End :Plain End, Beveled End, Treaded
Schedules :SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules

Carbon Steel DIN 17175 Pipe Chemical Composition

Grade		C	Si	Mn	S	P	Cr	Mo	V
Standard	Steel grade	C	Si	Mn	Max		Cr	Mo	V
DIN 17175	St35.8	=0.17	0.10-0.35	0.40-0.80	0.02	0.025	–	–	–
	St45.8	=0.21	0.10-0.35	0.40-1.2	0.02	0.025	–	–	–
	15Mo3	0.12-0.20	0.10-0.35	0.40-0.80	0.02	0.025	–	0.25-0.35	–
	13CrMo44	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.70-1.10	0.45-0.65	–
	10CrMo910	0.08-0.15	=0.50	0.40-0.70	0.02	0.025	2.00-2.5	0.90-1.20	–
	14MoV63	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.30-0.60	0.50-0.70	0.22-0.32
	12Cr1MoV	0.08-0.15	0.17-0.37	0.40-0.70	0.02	0.025	0.90-1.20	0.25-0.35	0.15-0.30

Carbon Steel DIN 17175 Pipe Mechanical Properties

Grade		C	Si	Mn	S	P	Cr	Mo	V
Standard	Steel grade	C	Si	Mn	Max		Cr	Mo	V
DIN 17175	St35.8	=0.17	0.10-0.35	0.40-0.80	0.02	0.025	–	–	–
	St45.8	=0.21	0.10-0.35	0.40-1.2	0.02	0.025	–	–	–
	15Mo3	0.12-0.20	0.10-0.35	0.40-0.80	0.02	0.025	–	0.25-0.35	–
	13CrMo44	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.70-1.10	0.45-0.65	–
	10CrMo910	0.08-0.15	=0.50	0.40-0.70	0.02	0.025	2.00-2.5	0.90-1.20	–
	14MoV63	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.30-0.60	0.50-0.70	0.22-0.32
	12Cr1MoV	0.08-0.15	0.17-0.37	0.40-0.70	0.02	0.025	0.90-1.20	0.25-0.35

If You Are Looking To Buy High Quality Pipes, Sheet, Fittings and Flanges

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Top Manufacturer and Supplier of Carbon Steel DIN 17175 Pipe in Canberra, Australia

Jaxon Steel is a reputed manufacturer and provider of high quality Carbon Steel DIN 17175 Pipe products at Canberra, Australia. Since we specialize in premium steel products, we deliver a wide selection of materials- Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Products offered include- Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Reliable deliveries and great customer service have defined us in commitment to the top-grade steel material that promises to last long, ensuring high performances in many applications in the industry. Jaxon Steel is here for all of your Carbon Steel DIN 17175 Pipe requirements.

Carbon Steel DIN 17175 Pipe Dimensions Chart

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

ASTM A335 DIN 17175 Pipe Exporter in Australia, DIN 17175 Carbon Steel Pipe Price List in Canberra, DIN 17175 CS Pipe Supplier in Adelaide, Carbon Steel DIN 17175 Pipes Exporter in Melbourne, Carbon Steel DIN 17175 Pipes Exporter in Sydney, DIN 17175 Pipes Size Chart, 17175 Carbon Steel Pipe Price in Brisbane, DIN 17175 Pipes CS Weight Chart, Carbon Steel DIN 17175 Pipes Thickness, CS DIN 17175 Pipes Supplier in Australia, 17175 Carbon Steel Thin Wall Pipe Stockist in Adelaide

Types of Carbon Steel DIN 17175 Pipe

Carbon Steel DIN 17175 Pipes Supplier in Canberra, 17175 Carbon Steel Thin Wall Pipe Exporter in Adelaide, CS DIN 17175 Pipes Manufacturer in Melbourne, Carbon Steel DIN 17175 Pipes Price List in Australia, DIN 17175 Pipes Carbon Steel Distributor in Sydney, 17175 CS Pipes in Brisbane, DIN 17175 Pipes Supplier in Melbourne, Carbon Steel DIN 17175 Pipes Distributor in Australia, CS DIN 17175 Pipe Sizes in mm

Uses of Carbon Steel DIN 17175 Pipe

You’ll find Carbon Steel DIN 17175 Pipes being used across various industries that need strong, durable, and heat-resistant piping solutions. They’re perfect for boilers, heat exchangers, pressure vessels, and piping systems in power plants, refineries, and petrochemical facilities. Their mechanical strength and ability to perform under high temperatures also make them suitable for heavy engineering, construction frameworks, and mechanical systems. Plus, these pipes are a staple in industrial plants where long-term reliability, operational safety, and consistent performance are essential.
