Travis Steel is a reputable manufacturer and supplier located in Canberra, Australia, focusing on high-quality HIC Resistant Steel Sheets and Plates that are specifically designed to resist hydrogen-induced cracking in sour and corrosive environments. Our HIC resistant steel products are crafted using cutting-edge steelmaking and rolling techniques, which guarantee exceptional toughness, strength, and durability. Built to comply with rigorous international standards, these sheets and plates offer outstanding weldability, formability, and resistance to stress corrosion. At Travis Steel, we pride ourselves on precision, consistent quality, and timely delivery, making our HIC Resistant Steel Sheets and Plates perfect for applications in oil & gas, petrochemical, pressure vessels, and heavy engineering.
These HIC Resistant Steel Sheets and Plates are primarily made from low-carbon steel, with carefully balanced alloying elements like manganese, chromium, nickel, and molybdenum to boost their resistance to hydrogen-induced cracking. They generally showcase a tensile strength ranging from 485 to 620 MPa and a yield strength of about 275 MPa, all while maintaining excellent ductility and toughness. With superior weldability and formability, these sheets and plates ensure safe fabrication and long-lasting performance in highly corrosive and high-pressure settings, where reliability and crack resistance are essential.
| Material | ASTM A516 |
| Grade | SA516 Gr 65, SA516 Gr 70 ,SA516 Gr 60 , Gr 60N |
| Size |
|
| Manufacturing Process | Â Hot-Rolled |
| Impact tested | -52° C |
Technical requirements | high strength and high toughness requirements, Detection, Z15 – Z35 thickness direction performance requirements, etc |
| Condition of Supply | Heat Treatment Simulated Post-Weld , Furnace Normalizing, As Rolled, Normalized Rolling, Vacuum Degassing or as per need |
| Base Plate | hot dipped zinc coated and  A-Z coated steel sheet, Cold rolled steel sheet |
Â
| C | ≤0.2 |
| Mn | 0.85–1.20 |
| Cu | ≤0.2 |
| Cev | ≤0.41 |
| S | ≤0.001 |
| Si | 0.15–0.40 |
| P | ≤0.010 |
| Mo | ≤0.1 |
| Ni | ≤0.4 |
| Cr | ≤0.3 |
| ASTM/ASME | DIN | European Norm | British Standard |
| A/SA516 – Grade 60 | DIN 17155 HII | EN10028 P265GH | BS1501-161-430A |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | Plates Thickness |
|---|---|
| A516 60 | ≤12.5mm |
| A516 60 | ≥100 and ≤200mm |
| A516 60 | ≥12.5 mm and ≤50mm |
| A516 60 | >200mm |
| A516 65 Dicrest only | ≥100 mm and ≤200mm |
| A516 60 | ≥50 mm and ≤100mm |
| A516 65 Dicrest only | ≤12.5mm |
| A516 65 Dicrest only | ≥12.5 mm and ≤50mm |
| A516 65 Dicrest only | ≥50 mm and ≤100 mm |
| A516 70 | >200 mm |
| A516 65 Dicrest only | >200mm |
| A516 70 | ≥100 mm and ≤200mm |
| A516 70 | ≤12.5mm |
| A516 70 | ≥50 mm and ≤100mm |
| A516 70 | ≥12.5 mm and ≤50mm |
| Lengths in mm | Plates Thickness in Inches | Widths in mm | Lbs/Sft |
|---|---|---|---|
| 240 | 7/16 Inches | 96 | 17.870 Lbs/Sft |
| 96, 120, 240 | 5/16 Inches | 60 ,48 , 84 , 72 ,96 | 12.760 Lbs/Sft |
| 96, 120, 124,133, 144, 156, 240 | 3/16 Inches | 7.660 Lbs/Sft | |
| 110, 96, 120, 240, 144 | 1/4 Inches | 10.210 Lbs/Sft | |
| 120, 96, 144, 169, 240, 260 | 3/8 Inches | 15.320 Lbs/Sft | |
| 120, 96, 144, 240 | 1/2 Inches | 20.420 Lbs/Sft | |
| 240 | 1 1/8 Inches | 96 | 45.950 Lbs/Sft |
| 96, 240, 120, 480 | 1 Inches | 48, 72, 96 | 40.840 Lbs/Sft |
| 96, 240, 120, 480 | 3/4 Inches | 48 , 72 , 84, 96 | 30.630 Lbs/Sft |
| 240 | 7/8 Inches | 96 | 35.740 Lbs/Sft |
| 240, 120, 480 | 5/8 Inches | 48 , 96 | 25.530 Lbs/Sft |
| 96, 120, 240 | 1 1/4 Inches | 48, 96 | 51.050 Lbs/Sft |
| 120, 240 | 1 1/2 Inches | 96 | 61.260 Lbs/Sft |
| 240 | 1 3/4 Inches | 71.470 Lbs/Sft | |
| 240 | 1 3/8 Inches | 56.160 Lbs/Sft | |
| 120, 240 | 2 Inches | 81.680 Lbs/Sft | |
| 240 | 2 1/2 Inches | 102.100 Lbs/Sft | |
| 1 5/8 Inches | 66.370 Lbs/Sft | ||
| 2 3/4 Inches | 112.310 Lbs/Sft | ||
| 2 1/4 Inches | 91.890 Lbs/Sft | ||
| 3 Inches | 122.520 Lbs/Sft | ||
| 120 | 3 1/2 Inches | 142.940 Lbs/Sft | |
| 120 | 6 Inches | 245.040 Lbs/Sft | |
| 120 | 3 3/4 Inches | 153.150 Lbs/Sft | |
| 144 | 3 1/4 Inches | 132.730 Lbs/Sft | |
| 144, 180 | 4 Inches | 163.360 Lbs/Sft | |
| 120 | 4 1/2 Inches | 183.780 Lbs/Sft | |
| 120 | 4 1/4 Inches | 173.570 Lbs/Sft | |
| 144 | 5 Inches | 204.200 Lbs/Sft | |
| 160 | 7 Inches | 285.880 Lbs/Sft |
HIC Resistant Steel Sheets and Plates find extensive use in industries that deal with sour gas, hydrogen sulfide, and other corrosive conditions. They’re commonly utilized in oil refineries, petrochemical plants, offshore platforms, pressure vessels, and storage tanks. Thanks to their remarkable toughness, mechanical strength, and resistance to hydrogen-induced cracking, they are ideal for pipelines, industrial equipment, and structural components in challenging environments. Travis Steel’s HIC Resistant Steel Sheets and Plates deliver enduring performance, safety, and reliability, ensuring structural integrity and operational efficiency across industrial, oil & gas, and heavy engineering sectors.
