Travis Steel stands out as a top-notch manufacturer and supplier located in Canberra, Australia, with a focus on delivering high-quality steel products, including the SA 516 GR.60/70N NACE HIC Plates. These plates are well-known for their durability and adherence to strict industry standards, specifically designed for sour service applications where it’s crucial to resist hydrogen-induced cracking (HIC). Travis Steel guarantees that every plate complies with NACE MR0175/ISO 15156 standards, providing outstanding strength, toughness, and corrosion resistance. With a strong commitment to excellence, cutting-edge manufacturing techniques, and prompt delivery, Travis Steel has become the go-to source for premium-grade steel plates throughout Australia and beyond.
The SA 516 GR.60/70N NACE HIC Plates are carbon steel plates that boast excellent notch toughness, making them perfect for pressure vessels that operate in moderate to low temperatures. Their chemical makeup typically includes carbon (≤0.30%), manganese (0.79–1.30%), phosphorus (≤0.035%), and sulfur (≤0.035%). These plates showcase impressive mechanical properties: GR.60 has a minimum tensile strength of 415–550 MPa, while GR.70 offers 485–620 MPa, with minimum yield strengths of 260 MPa and 275 MPa, respectively. The “N” signifies that the plates are in a normalized condition, which enhances both strength and ductility, while NACE HIC compliance ensures they can withstand sour gas environments.
| Grade | ASME SA 516 GR.60/70N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.20 | 0.4 | 0.95/1.50 | 0.025 | 0.025 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| 0.18 | 0.4 | 0.95/1.50 | 0.015 | 0.008 | 0.02 (Min) | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength | Yield strength | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 415-550 MPa | 250 MPa | 21 | 25 |
| 485-620 (70-90) | 260 (38) | 17 | 21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-161-430A | EN10028 P265GH | A/SA516 – Grade 60 | DIN 17155 HII |
| BS1501-224-490A/B | EN10028 P355GH | A/SA516 – Grade 70 | – |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.60/70N NACE and HIC Plates in Canberra, Australia. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.60/70N NACE and HIC Plates needs!
SA 516 GR.60/70N NACE HIC Plates find extensive use in industries that require exceptional resistance to hydrogen-induced cracking and superior mechanical strength. They’re commonly used in the fabrication of pressure vessels, heat exchangers, storage tanks, boilers, and reactors in oil and gas refineries, petrochemical plants, and offshore drilling platforms. These plates are particularly suited for sour service conditions, where exposure to hydrogen sulfide could jeopardize material integrity. Their robust performance under high pressure and corrosive environments makes them essential for critical operations, ensuring safety, durability, and reliability.
